Digital Radio DAB/FM XDR-P1DBP
Sony Corporation; Tokyo
- Country
- Japan
- Manufacturer / Brand
- Sony Corporation; Tokyo
- Year
- 2015
- Category
- Broadcast Receiver - or past WW2 Tuner
- Radiomuseum.org ID
- 277926
Click on the schematic thumbnail to request the schematic as a free document.
- Number of Transistors
- Semiconductors present.
- Semiconductors
- FS1445-A
- Main principle
- DSP, Digital Signal Processor
- Wave bands
- DAB and FM, perhaps with Streaming [DABFM]
- Power type and voltage
- Storage Battery for all (e.g. for car radios and amateur radios) / 3,6 Volt
- Loudspeaker
- Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 4.5 cm = 1.8 inch
- Power out
- 1.5 W (unknown quality)
- Material
- Plastics (no bakelite or catalin)
- from Radiomuseum.org
- Model: Digital Radio DAB/FM XDR-P1DBP - Sony Corporation; Tokyo
- Shape
- Very small Portable or Pocket-Set (Handheld) < 8 inch.
- Dimensions (WHD)
- 115 x 57 x 25 mm / 4.5 x 2.2 x 1 inch
- Notes
-
Sony Digital Radio XDR-P1DBP receives DAB/DAB+ and FM transmissions.
Ranges:
- DAB (Band III) channel 5A to 13F (174,928 to 239,200 MHz)
- FM 87.5 to 108 MHz, tunable in 50 kHz steps. RDS function.
Output: headphones jack 3.5 mm (stereophonic)
Input: DC in 5V (micro USB) recharges the Lithium-Ion battery of 1.300 mAh capacity.Battery life:
- When listening through the speaker: Approx. 15 hours
- When listening through the headphone: Approx. 20 hours
Made in China
- Net weight (2.2 lb = 1 kg)
- 0.170 kg / 0 lb 6 oz (0.374 lb)
