Discman, Compact Disc Compact Player D-20

Sony Corporation; Tokyo

Data

Forum

Pictures

Collections

Country
Japan

Manufacturer / Brand
Sony Corporation; Tokyo

Year
1988 ?

Category
Sound/Video Recorder and/or Player

Radiomuseum.org ID
291866

Schematics

Discman, Compact Disc Compact Player D-20; Sony Corporation; (ID = 2122690) R-Player — Sony Corporation; Discman, Compact Disc Compact Player D-20 (3)

Discman, Compact Disc Compact Player D-20; Sony Corporation; (ID = 2122914) R-Player — Sony Corporation; Discman, Compact Disc Compact Player D-20 (3)

Discman, Compact Disc Compact Player D-20; Sony Corporation; (ID = 2122915) R-Player — Sony Corporation; Discman, Compact Disc Compact Player D-20 (3)

Discman, Compact Disc Compact Player D-20; Sony Corporation; (ID = 2122916) R-Player — Sony Corporation; Discman, Compact Disc Compact Player D-20 (3)

Discman, Compact Disc Compact Player D-20; Sony Corporation; (ID = 2122917) R-Player — Sony Corporation; Discman, Compact Disc Compact Player D-20 (3)

Discman, Compact Disc Compact Player D-20; Sony Corporation; (ID = 2122918) R-Player — Sony Corporation; Discman, Compact Disc Compact Player D-20 (3)

Discman, Compact Disc Compact Player D-20; Sony Corporation; (ID = 2122919) R-Player — Sony Corporation; Discman, Compact Disc Compact Player D-20 (3)

Discman, Compact Disc Compact Player D-20; Sony Corporation; (ID = 2122921) R-Player — Sony Corporation; Discman, Compact Disc Compact Player D-20 (3)

Discman, Compact Disc Compact Player D-20; Sony Corporation; (ID = 2122922) R-Player — Sony Corporation; Discman, Compact Disc Compact Player D-20 (3)

Discman, Compact Disc Compact Player D-20; Sony Corporation; (ID = 2122923) R-Player — Sony Corporation; Discman, Compact Disc Compact Player D-20 (3)

Discman, Compact Disc Compact Player D-20; Sony Corporation; (ID = 2122924) R-Player — Sony Corporation; Discman, Compact Disc Compact Player D-20 (3)

Discman, Compact Disc Compact Player D-20; Sony Corporation; (ID = 2122925) R-Player — Sony Corporation; Discman, Compact Disc Compact Player D-20 (3)

Discman, Compact Disc Compact Player D-20; Sony Corporation; (ID = 2122926) R-Player — Sony Corporation; Discman, Compact Disc Compact Player D-20 (3)

Discman, Compact Disc Compact Player D-20; Sony Corporation; (ID = 2122927) R-Player — Sony Corporation; Discman, Compact Disc Compact Player D-20 (3)

Discman, Compact Disc Compact Player D-20; Sony Corporation; (ID = 2122928) R-Player — Sony Corporation; Discman, Compact Disc Compact Player D-20 (3)

Discman, Compact Disc Compact Player D-20; Sony Corporation; (ID = 2122929) R-Player — Sony Corporation; Discman, Compact Disc Compact Player D-20 (3)

Discman, Compact Disc Compact Player D-20; Sony Corporation; (ID = 2122554) R-Player — Sony Corporation; Discman, Compact Disc Compact Player D-20 (1)
Draufsicht

Discman, Compact Disc Compact Player D-20; Sony Corporation; (ID = 2122555) R-Player — Sony Corporation; Discman, Compact Disc Compact Player D-20 (1)
Frontansicht mit Display

Discman, Compact Disc Compact Player D-20; Sony Corporation; (ID = 2122556) R-Player — Sony Corporation; Discman, Compact Disc Compact Player D-20 (1)
Rechte Seite mit Kopfhörerbuchse

Discman, Compact Disc Compact Player D-20; Sony Corporation; (ID = 2122561) R-Player — Sony Corporation; Discman, Compact Disc Compact Player D-20 (1)
Deckel geöffnet

Discman, Compact Disc Compact Player D-20; Sony Corporation; (ID = 2122562) R-Player — Sony Corporation; Discman, Compact Disc Compact Player D-20 (1)
Linke Seite mit Remotebuchse

Discman, Compact Disc Compact Player D-20; Sony Corporation; (ID = 2122564) R-Player — Sony Corporation; Discman, Compact Disc Compact Player D-20 (1)

Discman, Compact Disc Compact Player D-20; Sony Corporation; (ID = 2122565) R-Player — Sony Corporation; Discman, Compact Disc Compact Player D-20 (1)
Unterseite

Discman, Compact Disc Compact Player D-20; Sony Corporation; (ID = 2123076) R-Player — Sony Corporation; Discman, Compact Disc Compact Player D-20 (1)
Bodenplatte entfernt, Hauptplatine

Discman, Compact Disc Compact Player D-20; Sony Corporation; (ID = 2123077) R-Player — Sony Corporation; Discman, Compact Disc Compact Player D-20 (1)
Hauptplatine

Discman, Compact Disc Compact Player D-20; Sony Corporation; (ID = 2123078) R-Player — Sony Corporation; Discman, Compact Disc Compact Player D-20 (1)
Laufwerk

Discman, Compact Disc Compact Player D-20; Sony Corporation; (ID = 2123079) R-Player — Sony Corporation; Discman, Compact Disc Compact Player D-20 (1)
Display und LS-Regler

Discman, Compact Disc Compact Player D-20; Sony Corporation; (ID = 2123080) R-Player — Sony Corporation; Discman, Compact Disc Compact Player D-20 (1)

Click on the schematic thumbnail to request the schematic as a free document.

Technical Specifications

Number of Transistors
Semiconductors present.

Semiconductors

Main principle
Audio-Amplification

Wave bands
- without

Details
CD-Player, -Writer, MD, MOD (audio); Hi-Fi equipment

Power type and voltage
Batteries / addl. power jack / AA: 4 x 1,5 / 9 Volt

Loudspeaker
- For headphones or amp.

Material
Plastics (no bakelite or catalin)

from Radiomuseum.org
Model: Discman, Compact Disc Compact Player D-20 - Sony Corporation; Tokyo

Shape
Very small Portable or Pocket-Set (Handheld) < 8 inch.

Dimensions (WHD)
136 x 38 x 149 mm / 5.4 x 1.5 x 5.9 inch

Notes
A small portable stereo compact disc player powered either by 4 x AA batteries or the supplied 9 volt AC mains adaptor. Can also be powered by a car battery via the optional CPM-100P car mounting kit which plugs into the car cigar lighter. Jacks for DC In 9V, Line Out, Phones and Remote. Track number display.

Frequency Response: 20 - 20,000 Hz +1dB,-3dB
Line Out: 1V at 47kΩ, Load Impedance over 10kΩ
Phones: 9mW + 9mW at 32Ω

Supplied Accessories
AC Power Adaptor
Connecting cord
Carrying belt

Optional Accessories
Car Mount plate CPM-100P

9V mains adaptor versions
AEP AC-940AEP model: 220V AC 50Hz
UK AC-930A model: 240V AC 50Hz
E AC-950W model: 110 - 240 V adjustable
Australia AC-930A model: 240V AC 50Hz

Power Consumption: 1.2W DC

Very similar to the Sony D-2 (US & Canada models) Discman.

Europäische Version "D-20", US-Model "D-2", Betrieb mit 4 Batterien, Typ AA, 6 Volt, oder opt. Netzteil mit Hohlstecker, 9 Volt, Plus außen.

Net weight (2.2 lb = 1 kg)
0.450 kg / 0 lb 15.9 oz (0.991 lb)

Literature/Schematics (1)
- - Manufacturers Literature (Service Manual D-2/20)

Author
Model page created by Michael Schott. See "Data change" for further contributors.

Other Models
Here you find 3993 models, 3854 with images and 957 with schematics for wireless sets etc. In French: TSF for Télégraphie sans fil.
All listed radios etc. from Sony Corporation; Tokyo

Collections | Museums | Literature

Collections

The model Discman, Compact Disc Compact Player is part of the collections of the following members.

Michael Schott (D)

Forum

Forum contributions about this model: Sony Corporation;: Discman, Compact Disc Compact Player D-20

Threads: 1 | Posts: 2

Guten Abend!

Ich habe eine Bitte: Ich habe seit einigen Tagen einen Diskman Sony D-20 (angebl. baugleich mit US-Version D-2). Das gute Stück bräuchte einen Service; er sollte als Diskman nicht so leicht "aus dem Tritt" gebracht werden können, aber das ist hier doch der Fall. Die Serviceunterlagen liegen vor, habe ich inzwischen hier hochgeladen, schicke ich aber gern auch als PDF per Mail, falls hier nichts dagegen spricht (stammen ja aus meinem Besitz)?

Aus sicherlich verständlichen Gründen möchte ich das schöne Stück keiner "normalen" Werkstatt anvertrauen, sondern würde mich freuen, wenn mir ein Mitglied den Service machen könnte, der Freude an der Technik hat, wie wir alle hier. Das ganze natürlich gegen Erstattung aller Kosten, inkl. Hin-, und Rückversand.

Ich würde mich über entsprechende Angebote sehr freuen!

Mit freundlichem Gruß.

Michael Schott

Michael Schott, 17.Jun.17
