FM/AM Cassette Stereo XR-4402

Sony Corporation; Tokyo

Data
Forum
Pictures
Collections

  • Year
  • 1993 ?
  • Category
  • Car Radio, perhaps also + sound player/recorder
  • Radiomuseum.org ID
  • 217574

Click on the schematic thumbnail to request the schematic as a free document.

 Technical Specifications

  • Number of Transistors
  • Semiconductors present.
  • Semiconductors
  • Main principle
  • PLL, Phase-locked loop
  • Wave bands
  • Broadcast (BC) and FM or UHF.
  • Details
  • Cassette-Recorder or -Player
  • Power type and voltage
  • Storage Battery for all (e.g. for car radios and amateur radios) / 12 Volt
  • Loudspeaker
  • - This model requires external speaker(s).
  • Power out
  • 80 W (unknown quality)
  • Material
  • Metal case
  • from Radiomuseum.org
  • Model: FM/AM Cassette Stereo XR-4402 - Sony Corporation; Tokyo
  • Shape
  • Chassis only or for «building in»
  • Dimensions (WHD)
  • 182 x 53 x 154 mm / 7.2 x 2.1 x 6.1 inch
  • Notes
  • Sony Car Radio XR-4402 (German Model) 4x 20 Watt Musikleistung an 4 Ohm, digitale Frequenzanzeige.
  • Net weight (2.2 lb = 1 kg)
  • 1.3 kg / 2 lb 13.8 oz (2.863 lb)
  • Price in first year of sale
  • 449.00 DM
  • Mentioned in
  • Original Sony Service Unterlagen
  • Author
  • Model page created by Josef Pilz. See "Data change" for further contributors.
