FM/AM Radio ICF-S12

Sony Corporation; Tokyo

Data
Forum
Pictures
Collections

  • Year
  • 1994 ?
  • Category
  • Broadcast Receiver - or past WW2 Tuner
  • Radiomuseum.org ID
  • 204584

Click on the schematic thumbnail to request the schematic as a free document.

 Technical Specifications

  • Number of Transistors
  • Semiconductors present.
  • Main principle
  • Superheterodyne (common); ZF/IF 455/10700 kHz
  • Wave bands
  • Broadcast (BC) and FM or UHF.
  • Power type and voltage
  • Dry Batteries / 2 x 1.5 Volt
  • Loudspeaker
  • Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 5.7 cm = 2.2 inch
  • Power out
  • 0.1 W (unknown quality)
  • Material
  • Plastics (no bakelite or catalin)
  • from Radiomuseum.org
  • Model: FM/AM Radio ICF-S12 - Sony Corporation; Tokyo
  • Shape
  • Very small Portable or Pocket-Set (Handheld) < 8 inch.
  • Dimensions (WHD)
  • 70 x 118 x 32 mm / 2.8 x 4.6 x 1.3 inch
  • Notes
  • Battery life using Sony batteries SUM-3(NS)
    Speaker FM: Approx. 40 hours, AM: Approx 45 hours
    Earphone FM: Approx. 94 hours, AM Approx. 120 hors
    (listening four hours a day at normal volume)
  • Net weight (2.2 lb = 1 kg)
  • 0.2 kg / 0 lb 7 oz (0.441 lb)
