HMK-70
Sony Corporation; Tokyo
- Country
- Japan
- Manufacturer / Brand
- Sony Corporation; Tokyo
- Year
- 1975
- Category
- Broadcast Receiver - or past WW2 Tuner
- Radiomuseum.org ID
- 128710
Q: Sony, Produkt-Katalog 1976
Click on the schematic thumbnail to request the schematic as a free document.
- Number of Transistors
- Semiconductors present.
- Semiconductors
- Main principle
- Superheterodyne (common); ZF/IF 468/10700 kHz
- Wave bands
- Broadcast, Long Wave and FM or UHF.
- Details
- Other Combination - see Notes
- Power type and voltage
- Alternating Current supply (AC) / 110; 127; 220; 240 Volt
- Loudspeaker
- - This model requires external speaker(s).
- Material
- Various materials
- from Radiomuseum.org
- Model: HMK-70 - Sony Corporation; Tokyo
- Shape
- Tablemodel, low profile (big size).
- Dimensions (WHD)
- 626 x 191 x 420 mm / 24.6 x 7.5 x 16.5 inch
- Notes
- "Stereo Music System", built-in cassette recorder and record disc player, plexi hood. 2 x 28 W DIN/ 2 x 35 W Musik.
- Net weight (2.2 lb = 1 kg)
- 19.4 kg / 42 lb 11.7 oz (42.731 lb)
- Source of data
- -- Collector info (Sammler)
- Mentioned in
- (A) Radio Elektronik Schau; Heft 11, 1975 Werbeschaltung
- Author
- Model page created by a member from A. See "Data change" for further contributors.
