Home Theatre System DAV-SA30 (HCD-SA30)

Sony Corporation; Tokyo

Data
Forum
Pictures
Collections

  • Year
  • 2003
  • Category
  • Broadcast Receiver - or past WW2 Tuner
  • Radiomuseum.org ID
  • 340244

 Technical Specifications

  • Number of Transistors
  • Semiconductors present.
  • Semiconductors
  • Main principle
  • DSP, Digital Signal Processor; ZF/IF 450/10700 kHz
  • Wave bands
  • Broadcast (BC) and FM or UHF.
  • Details
  • CD-DVD-VMD-Blu-ray for video; Radio with other functions
  • Power type and voltage
  • Alternating Current supply (AC) / 50-60 Hz, 230 Volt
  • Loudspeaker
  • - This model requires external speaker(s).
  • Power out
  • 480 W (unknown quality)
  • Material
  • Various materials
  • from Radiomuseum.org
  • Model: Home Theatre System DAV-SA30 - Sony Corporation; Tokyo
  • Shape
  • Book-shelf unit.
  • Dimensions (WHD)
  • 355 x 75 x 360 mm / 14 x 3 x 14.2 inch
  • Notes

  • Sony Home Theatre System DAV-SA30 includes unit HCD-SA30 (amplifier, DVD/SACD and tuner section).

    Specifications:

    • Formats: DVD, VCD, SACD, CD, MP3, Tuner
    • Remote control: infra red
    • Power output: 44 W per channel into 6 Ω
    • Frequency response: 20 - 20.000 Hz
    • Total harmonic distortion: 10%.

    Power supply options:

    • Europe:   50-60 Hz, 230 V
    • Australian and Asia:   50-60 Hz, 230-240 V
    • Canada and Mexico:   60 Hz, 120 V
    • Saudi Arabia:   50-60 Hz, 120-127; 220; 230-240 V.
  • Net weight (2.2 lb = 1 kg)
  • 5.9 kg / 12 lb 15.9 oz (12.996 lb)
  • Author
  • Model page created by Francisco Martins. See "Data change" for further contributors.
