• Year
  • 1990
  • Category
  • Broadcast Receiver - or past WW2 Tuner
  • Radiomuseum.org ID
  • 207618

Click on the schematic thumbnail to request the schematic as a free document.

 Technical Specifications

  • Number of Transistors
  • Main principle
  • Superheterodyne (common); ZF/IF 455/10700 kHz
  • Wave bands
  • Long Wave and FM or UHF
  • Details
  • Radio with other functions
  • Power type and voltage
  • Dry Batteries / C: 3 x 1,5 Volt
  • Loudspeaker
  • Electro Magnetic Dynamic LS (moving-coil with field excitation coil) / Ø 6.6 cm = 2.6 inch
  • Power out
  • 0.22 W (unknown quality)
  • Material
  • Plastics (no bakelite or catalin)
  • from Radiomuseum.org
  • Model: ICF-3100L - Sony Corporation; Tokyo
  • Shape
  • Very small Portable or Pocket-Set (Handheld) < 8 inch.
  • Dimensions (WHD)
  • 112 x 159 x 58 mm / 4.4 x 6.3 x 2.3 inch
  • Notes
  • Sony ICF-3100L mit Bewegungsmelder (supersonic wave sensor)
    • The supersonic wave sensor detects when a person or an object comes near by, and turns on the radio automatically.
    • TUNE indicator enables precise tuning.
    • The timer turns off the radio automatically after the radio has been turned on by the supersonic wave sensor.
    • Easy installation on the wall using the ring on the rear.

    • Frequency range: LW and FM
    • Batterylife: using Sony batteries SUM-2(NS)
      • Approx. 90 hours when the POWER switch is set to ON
      • Approx. 90 days when the POWER switch is set to STANDBY
  • Net weight (2.2 lb = 1 kg)
  • 0.5 kg / 1 lb 1.6 oz (1.101 lb)
  • Mentioned in
  • -- Original-techn. papers. (Service-Manual)
