• Country
• Japan

• Manufacturer / Brand
• Sony Corporation; Tokyo

• Year
• 1988

• Category
• Broadcast Receiver - or past WW2 Tuner

• Radiomuseum.org ID
• 121106

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Transistors
• 1

• Semiconductors
• 2SC945 CXA1019M

• Main principle
• Superheterodyne (common)

• Wave bands
• Broadcast, Long Wave and FM or UHF.

• Power type and voltage
• Dry Batteries / 3 x 1,5 Volt

• Loudspeaker
• Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) - elliptical / Ø 3 inch = 7.6 cm

• Power out
• 0.2 W (unknown quality)

• Material
• Plastics (no bakelite or catalin)

• from Radiomuseum.org
• Model: ICF-450L - Sony Corporation; Tokyo

• Shape
• Very small Portable or Pocket-Set (Handheld) < 8 inch.

• Dimensions (WHD)
• 196 x 95 x 40 mm / 7.7 x 3.7 x 1.6 inch

• Notes
• 1 IC.

• Net weight (2.2 lb = 1 kg)
• 0.4 kg / 0 lb 14.1 oz (0.881 lb)

• Literature/Schematics (1)
• -- Schematic

• Author
• Model page created by Pius Steiner. See "Data change" for further contributors.
