• Country
• Japan

• Manufacturer / Brand
• Sony Corporation; Tokyo

• Year
• 1991 ?

• Category
• Audio Amplifier or -mixer

• Radiomuseum.org ID
• 244726

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Transistors
• Semiconductors present.

• Semiconductors

• Main principle
• Audio-Amplification

• Wave bands
• - without

• Details
• Hi-Fi equipment

• Power type and voltage
• Alternating Current supply (AC) / 220-230 Volt

• Loudspeaker
• - This model requires external speaker(s).

• Power out
• 160 W (undistorted)

• Material
• Metal case

• from Radiomuseum.org
• Model: Integrated Stereo Amplifier TA-F270 - Sony Corporation; Tokyo

• Shape
• Book-shelf unit.

• Dimensions (WHD)
• 430 x 135 x 372 mm / 16.9 x 5.3 x 14.6 inch

• Notes

• HiFi-Vollverstärker.

• Net weight (2.2 lb = 1 kg)
• 8.9 kg / 19 lb 9.7 oz (19.604 lb)

• Literature/Schematics (1)
• -- Original-techn. papers.

• Author
• Model page created by a member from D. See "Data change" for further contributors.
