• Country
• Japan

• Manufacturer / Brand
• Sony Corporation; Tokyo

• Year
• 1978

• Category
• Broadcast Receiver - or past WW2 Tuner

• Radiomuseum.org ID
• 156199

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Transistors
• Semiconductors present.

• Semiconductors

• Main principle
• Superheterodyne (common)

• Wave bands
• Wave Bands given in the notes.

• Power type and voltage
• Other, details in remarks or not known. / 6; 4 x 1,5 Volt

• Loudspeaker
• Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil)

• Material
• Plastics (no bakelite or catalin)

• from Radiomuseum.org
• Model: Newscaster ICF-7800W - Sony Corporation; Tokyo

• Shape
• Very small Portable or Pocket-Set (Handheld) < 8 inch.

• Dimensions (WHD)
• 136 x 95 x 70 mm / 5.4 x 3.7 x 2.8 inch

• Notes
• Sony Newscaster ICF-7800W;
  Coverage: FM/AM/US VHF Hi Police Band,
  AFC/Squelch switch, bass & treble control, timer/tuning instrument, two telescopic antennas, folds-out, 6 VDC in, MPX out, earphones & tape jack, compare with Sony "ICF-7800" but different coverage!

• Author
• Model page created by a member from A. See "Data change" for further contributors.
