• Country
• Japan

• Manufacturer / Brand
• Sony Corporation; Tokyo

• Year
• 1985 ??

• Category
• Broadcast Receiver - or past WW2 Tuner

• Radiomuseum.org ID
• 359627

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Transistors
• Semiconductors present.

• Semiconductors

• Main principle
• Superheterodyne (common)

• Wave bands
• Broadcast (BC) and FM or UHF.

• Power type and voltage
• Dry Batteries / AA: 3 × 1.5 Volt

• Loudspeaker
• 2 Loudspeakers / Ø 2.25 inch = 5.7 cm

• Power out
• 0.4 W (unknown quality)

• Material
• Plastics (no bakelite or catalin)

• from Radiomuseum.org
• Model: Slim FM-AM Stereo Radio HFM-850ST - Sony Corporation; Tokyo

• Shape
• Portable set > 8 inch (also usable without mains)

• Dimensions (WHD)
• 230 x 78 x 35 mm / 9.1 x 3.1 x 1.4 inch

• Notes

• Made in Hong Kong

• Net weight (2.2 lb = 1 kg)
• 0.355 kg / 0 lb 12.5 oz (0.782 lb)

• Author
• Model page created by Nikolai Galak. See "Data change" for further contributors.
