Sony-O-Matic TC-357-4
Sony Corporation; Tokyo
- Country
- Japan
- Manufacturer / Brand
- Sony Corporation; Tokyo
- Year
- 1964–1966
- Category
- Sound/Video Recorder and/or Player
- Radiomuseum.org ID
- 334524
- Number of Tubes
- 3
- Main principle
- Audio-Amplification
- Wave bands
- - without
- Power type and voltage
- Alternating Current supply (AC) / 100; 110; 117; 125; 220; 240 Volt
- Loudspeaker
- Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) - elliptical
- Power out
- 2 W (max.)
- Material
- Leather / canvas / plastic - over other material
- from Radiomuseum.org
- Model: Sony-O-Matic TC-357-4 - Sony Corporation; Tokyo
- Shape
- Tablemodel, with any shape - general.
- Dimensions (WHD)
- 14.8 x 7.9 x 12.2 inch / 376 x 201 x 310 mm
- Notes
-
Sony TC-357-4 Tape Recorder
Features "Sony-O-Matic" control - completely automatic recording level control system. Self-threading "Sony-O-Matic reel. Three speeds, 7" reel. Easy tape loading with "retractomatic" pinch roller. (MINGAY'S PRICE SERVICE)
Tape Speeds: 7½ ips, 3¾ ips or 1⅞ ips (19, 9.5 or 4.75 cm/s)
Tracks: 4 Track, monophonic
Recording Time (Super 7 Tape):
45 minutes per track, 3 hours in total at 7½ ips
1.5 hours per track, 6 hours in total at 3¾ ips
3 hours per track, 12 hours in total at 1⅞ ips
Frequency Response:
40~15,000 c/s (Hz) at 7½ ips
40~12,000 c/s (Hz) at 3¾ ips
40~6,000 c/s (Hz) at 1⅞ ips
Flutter and Wow:
Less than 0.12% RMS at 7½ ips
Less than 0.20% RMS at 3¾ ips
Bias Frequency: Approx. 55 Kc (kHz)
Speaker: 6" x 4" (15 x 10 cm) PM dynamic, 8Ω
- Net weight (2.2 lb = 1 kg)
- 22 lb 0 oz (22 lb) / 9.988 kg
- Price in first year of sale
- 99.75 AUS £
- Mentioned in
- Mingay's Price Service (Feb 1965 to Aug 1966.)
- Literature/Schematics (1)
- -- Original-techn. papers. (Sony Servicing Guide, Nov 1965.)
- Author
- Model page created by Martin Kent. See "Data change" for further contributors.
