SQ Decoder / Amplifier SQA-200

Sony Corporation; Tokyo

  • Year
  • 1973 ?
  • Category
  • Audio Amplifier or -mixer
  • Radiomuseum.org ID
  • 226024

 Technical Specifications

  • Number of Transistors
  • 42
  • Semiconductors
  • Main principle
  • Audio-Amplification
  • Wave bands
  • - without
  • Power type and voltage
  • Alternating Current supply (AC) / 110; 127; 220; 240 Volt
  • Loudspeaker
  • - This model requires external speaker(s).
  • Power out
  • 16 W (30 W max.)
  • Material
  • Wooden case
  • from Radiomuseum.org
  • Model: SQ Decoder / Amplifier SQA-200 - Sony Corporation; Tokyo
  • Shape
  • Book-shelf unit.
  • Dimensions (WHD)
  • 312 x 73 x 280 mm / 12.3 x 2.9 x 11 inch
  • Notes
  • Sony SQ Decoder/Amplifier SQA-200 is a combined stereo quadrophonic sound decoder and amplifier for two back speakers as an addition to an existing stereo system for four-channel reproduction. When playing 4-channel SQ records, the special decoder in the SQA-200 provides reproduction of the original program on four separate channels.

  • Net weight (2.2 lb = 1 kg)
  • 3.650 kg / 8 lb 0.6 oz (8.04 lb)
  • Source of data
  • - - Manufacturers Literature
  • Author
  • Model page created by Abu Bakar. See "Data change" for further contributors.
