Stereo Amplifier TAN-8250

Sony Corporation; Tokyo

Data
Forum
Pictures
Collections

  • Year
  • 1974
  • Category
  • Audio Amplifier or -mixer
  • Radiomuseum.org ID
  • 287230

Click on the schematic thumbnail to request the schematic as a free document.

 Technical Specifications

  • Number of Transistors
  • Semiconductors present.
  • Semiconductors
  • Main principle
  • Audio-Amplification
  • Wave bands
  • - without
  • Details
  • Hi-Fi equipment
  • Power type and voltage
  • Alternating Current supply (AC) / 120 Volt
  • Loudspeaker
  • - This model requires external speaker(s).
  • Power out
  • 300 W (undistorted)
  • Material
  • Metal case
  • from Radiomuseum.org
  • Model: Stereo Amplifier TAN-8250 - Sony Corporation; Tokyo
  • Shape
  • Book-shelf unit.
  • Dimensions (WHD)
  • 440 x 170 x 410 mm / 17.3 x 6.7 x 16.1 inch
  • Notes

  • Sony Sterep Power Amplifier Model TAN-8250.
    Power output:
    150 watts RMS per channel into 8Ω (stereo) (20 - 20000Hz)
    200 watts RMS per channel into 4Ω (stereo) (20 - 20000Hz)
    Frequency response: 1Hz to 100kHz
    Total harmonic distortion: 0.2%
    Damping factor: 250
    Input sensitivity: 1V
    Signal to noise ratio: 100dB
    Speaker: A, B, A+B, Speaker load impedance: 2Ω to 16Ω
    AC Outlet: 1x Unswitched max. 200 Watts
    Power Consumption 380 Watts
    Wooden Side Panels



  • Net weight (2.2 lb = 1 kg)
  • 23.3 kg / 51 lb 5.1 oz (51.322 lb)
  • Mentioned in
  • - - Manufacturers Literature (Service Manual)
  • Author
  • Model page created by Franz Scharner. See "Data change" for further contributors.
