• Country
• Japan

• Manufacturer / Brand
• Sony Corporation; Tokyo

• Year
• 1970–1975

• Category
• Broadcast Receiver - or past WW2 Tuner

• Radiomuseum.org ID
• 158379

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Transistors
• 40

• Semiconductors

• Main principle
• Superheterodyne (common)

• Wave bands
• Broadcast (BC) and FM or UHF.

• Power type and voltage
• Alternating Current supply (AC) / 100; 120; 220; 240 Volt

• Loudspeaker
• - This model requires external speaker(s).

• Power out
• 44 W (unknown quality)

• Material
• Wooden case

• from Radiomuseum.org
• Model: FM Stereo / FM-AM Receiver STR-6036 - Sony Corporation; Tokyo

• Shape
• Book-shelf unit.

• Dimensions (WHD)
• 434 x 144 x 345 mm / 17.1 x 5.7 x 13.6 inch

• Notes
• Ausgangsleistung: 2× 22 W/8 Ω, 2× 25 W/4 Ω.
  Eingänge: Phono MM, Aux, Tape (RCA), Tape (DIN), Mic (L+R); Double 300-Ω-UKW-Antenne; AM-Antenne.

• Net weight (2.2 lb = 1 kg)
• 7.6 kg / 16 lb 11.8 oz (16.74 lb)

• Price in first year of sale
• 798.00 DM

• Literature/Schematics (1)
• Selezione Radio-TV Dezember 1972

• Author
• Model page created by Eduard Abfalterer. See "Data change" for further contributors.
