TC-160

Sony Corporation; Tokyo

Data

Forum

Pictures

Collections

Country
Japan

Manufacturer / Brand
Sony Corporation; Tokyo

Year
1971–1974

Category
Sound/Video Recorder and/or Player

Radiomuseum.org ID
114183

Schematics

TC-160; Sony Corporation; (ID = 710671) R-Player — Sony Corporation; TC-160 (3)

TC-160; Sony Corporation; (ID = 710672) R-Player — Sony Corporation; TC-160 (3)

TC-160; Sony Corporation; (ID = 710673) R-Player — Sony Corporation; TC-160 (3)

TC-160; Sony Corporation; (ID = 710674) R-Player — Sony Corporation; TC-160 (3)

TC-160; Sony Corporation; (ID = 710675) R-Player — Sony Corporation; TC-160 (3)

TC-160; Sony Corporation; (ID = 1171737) R-Player — Sony Corporation; TC-160 (1)

TC-160; Sony Corporation; (ID = 710665) R-Player — Sony Corporation; TC-160 (2)
Service Manual

TC-160; Sony Corporation; (ID = 765867) R-Player — Sony Corporation; TC-160 (2)

TC-160; Sony Corporation; (ID = 1169899) R-Player — Sony Corporation; TC-160 (2)
(c) The Popular Science, August '71

TC-160; Sony Corporation; (ID = 1169902) R-Player — Sony Corporation; TC-160 (1)
The main feature - the dual capstan drive.

TC-160; Sony Corporation; (ID = 1169905) R-Player — Sony Corporation; TC-160 (1)

TC-160; Sony Corporation; (ID = 1169909) R-Player — Sony Corporation; TC-160 (1)

TC-160; Sony Corporation; (ID = 1169912) R-Player — Sony Corporation; TC-160 (1)

TC-160; Sony Corporation; (ID = 1169915) R-Player — Sony Corporation; TC-160 (1)

TC-160; Sony Corporation; (ID = 1169918) R-Player — Sony Corporation; TC-160 (1)
The main feature - the dual capstan drive.

TC-160; Sony Corporation; (ID = 1169920) R-Player — Sony Corporation; TC-160 (1)

TC-160; Sony Corporation; (ID = 1169926) R-Player — Sony Corporation; TC-160 (1)

TC-160; Sony Corporation; (ID = 1170215) R-Player — Sony Corporation; TC-160 (1)

TC-160; Sony Corporation; (ID = 1170217) R-Player — Sony Corporation; TC-160 (1)

TC-160; Sony Corporation; (ID = 1171734) R-Player — Sony Corporation; TC-160 (1)

TC-160; Sony Corporation; (ID = 1171735) R-Player — Sony Corporation; TC-160 (1)

TC-160; Sony Corporation; (ID = 1171736) R-Player — Sony Corporation; TC-160 (1)

TC-160; Sony Corporation; (ID = 1171738) R-Player — Sony Corporation; TC-160 (1)

TC-160; Sony Corporation; (ID = 1661138) R-Player — Sony Corporation; TC-160 (2)

TC-160; Sony Corporation; (ID = 1661139) R-Player — Sony Corporation; TC-160 (2)

TC-160; Sony Corporation; (ID = 1661140) R-Player — Sony Corporation; TC-160 (2)

TC-160; Sony Corporation; (ID = 1661141) R-Player — Sony Corporation; TC-160 (2)

TC-160; Sony Corporation; (ID = 1661142) R-Player — Sony Corporation; TC-160 (2)

TC-160; Sony Corporation; (ID = 1661143) R-Player — Sony Corporation; TC-160 (2)

TC-160; Sony Corporation; (ID = 1921330) R-Player — Sony Corporation; TC-160 (1)
Collection Personnel

TC-160; Sony Corporation; (ID = 2844843) R-Player — Sony Corporation; TC-160 (2)
Sony Service Manual

Click on the schematic thumbnail to request the schematic as a free document.

Technical Specifications

Number of Transistors
18

Semiconductors

Main principle
Audio-Amplification

Wave bands
- without

Details
Cassette-Recorder or -Player

Power type and voltage
Alternating Current supply (AC) / 110; 127; 220; 240 Volt

Loudspeaker
- For headphones or amp.

Material
Various materials

from Radiomuseum.org
Model: TC-160 - Sony Corporation; Tokyo

Shape
Book-shelf unit.

Dimensions (WHD)
400 x 127 x 276 mm / 15.7 x 5 x 10.9 inch

Notes
Stereo-Kassettengerät; im Eingang MOSFET 2SK35; Bandgeschwindigkeit: 4,75 cm/s, Fe203- und Cr02-Bänder. Übertragungsbereich: 20···18000 Hz. Eingänge: Mikrofon, Tonband, Plattenspieler, Radio; Ausgang 2× 0,5 V an 8,2 kOhm und Kopfhörer 2× 1,55 V.

Net weight (2.2 lb = 1 kg)
6 kg / 13 lb 3.5 oz (13.216 lb)

Price in first year of sale
195.95 $

Literature/Schematics (1)
Magnetofony 2, 1971-1975, Bozdech J.

Author
Model page created by Wolfgang Lill. See "Data change" for further contributors.
