TFM1600
Sony Corporation; Tokyo
- Country
- Japan
- Manufacturer / Brand
- Sony Corporation; Tokyo
- Year
- 1969
- Category
- Broadcast Receiver - or past WW2 Tuner
- Radiomuseum.org ID
- 94728
Click on the schematic thumbnail to request the schematic as a free document.
- Number of Transistors
- 17
- Main principle
- Superhet with RF-stage; ZF/IF 455 kHz
- Wave bands
- Broadcast, more than 2 SW bands plus FM or UHF.
- Power type and voltage
- Line / Batteries (any type) / 100; 117; 220; 240; (4 × 1,5) Volt
- Loudspeaker
- Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 20 cm = 7.9 inch
- Material
- Plastics (no bakelite or catalin)
- from Radiomuseum.org
- Model: TFM1600 - Sony Corporation; Tokyo
- Shape
- Portable set > 8 inch (also usable without mains)
- Dimensions (WHD)
- 290 x 290 x 100 mm / 11.4 x 11.4 x 3.9 inch
- Notes
-
17 Transistors listed one per type, 7 Diodes and 2 rectifier Diodes.
- Net weight (2.2 lb = 1 kg)
- 3.6 kg / 7 lb 14.9 oz (7.93 lb)
- Source of data
- - - Data from my own collection
- Mentioned in
- -- Schematic (Schemario Radio Autoradio Mangianastri edizioni "Il Rostro" Italy, marzo 1971.)
- Author
- Model page created by Salvador Galan-Ocaña. See "Data change" for further contributors.
