• Country
• Japan

• Manufacturer / Brand
• Sony Corporation; Tokyo

• Year
• 1965 ??

• Category
• Broadcast Receiver - or past WW2 Tuner

• Radiomuseum.org ID
• 107892

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Transistors
• 8

• Semiconductors
• 2SA162 2SA124 2SA122 2SA122 2SA122 2SD65 2SD65 2SD65

• Main principle
• Superheterodyne (common); ZF/IF 455/10700 kHz; 2 AF stage(s)

• Tuned circuits
• 5 AM circuit(s)     8 FM circuit(s)

• Wave bands
• Broadcast, Long Wave and FM or UHF.

• Power type and voltage
• Dry Batteries / 6 x 1,5 Volt

• Loudspeaker
• 2 Loudspeakers / Ø 5.7 cm = 2.2 inch

• Power out
• 0.2 W (unknown quality)

• Material
• Plastics (no bakelite or catalin)

• from Radiomuseum.org
• Model: TFM-834L - Sony Corporation; Tokyo

• Shape
• Very small Portable or Pocket-Set (Handheld) < 8 inch.

• Dimensions (WHD)
• 165 x 92 x 44 mm / 6.5 x 3.6 x 1.7 inch

• Notes

• TFM-834L with leather case

  Es gibt auch ein Modell Sony TFM-834 ohne LW.

• Net weight (2.2 lb = 1 kg)
• 0.520 kg / 1 lb 2.3 oz (1.145 lb)

• Author
• Model page created by Peter Hoddow. See "Data change" for further contributors.
