• Country
• Japan

• Manufacturer / Brand
• Sony Corporation; Tokyo

• Year
• 1988 ?

• Category
• Television Receiver (TV) or Monitor

• Radiomuseum.org ID
• 173833

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Tubes
• 1

• Valves / Tubes
• A13JZV00X

• Number of Transistors
• Semiconductors present.

• Semiconductors

• Main principle
• Superheterodyne (common)

• Wave bands
• VHF incl. FM and/or UHF (see notes for details)

• Details
• Video-Taperecorder/-Player; Remote Control (with wire or wireless)

• Power type and voltage
• Line / Batteries (any type) / 220-240 / 12; 24 Volt

• Loudspeaker
• Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 6 cm = 2.4 inch

• Power out
• 0.5 W (unknown quality)

• Material
• Plastics (no bakelite or catalin)

• from Radiomuseum.org
• Model: Video 8 Combo - Trinitron Colour Video TV EV-DT1 - Sony Corporation; Tokyo

• Shape
• Tablemodel, with any shape - general.

• Dimensions (WHD)
• 160 x 230 x 300 mm / 6.3 x 9.1 x 11.8 inch

• Notes

• Video 8 Combo - Sony Trinitron Colour Video TV EV-DT1;
  Monitor with video 8 recorder, PAL standard, CCIR B/G electronic tuner, RCA AV in/out.

• Net weight (2.2 lb = 1 kg)
• 5.7 kg / 12 lb 8.9 oz (12.555 lb)

• Author
• Model page created by a member from A. See "Data change" for further contributors.
