• Country
• United States of America (USA)

• Manufacturer / Brand
• Sony Corporation of America; New York, NY

• Year
• 1965 ??

• Category
• Broadcast Receiver - or past WW2 Tuner

• Radiomuseum.org ID
• 336947

• Number of Transistors
• 5

• Semiconductors

• Main principle
• Superheterodyne (common)

• Wave bands
• Broadcast only (MW).

• Power type and voltage
• Alternating Current supply (AC) / 120 Volt

• Loudspeaker
• Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 3 inch = 7.6 cm

• Power out
• 1 W (undistorted)

• Material
• Wooden case

• from Radiomuseum.org
• Model: 8RC-34A - Sony Corporation of America;

• Shape
• Tablemodel with Clock ((Alarm-) Clock Radio).

• Dimensions (WHD)
• 12 x 5 x 6 inch / 305 x 127 x 152 mm

• Notes

• Made in USA by Esquire Radio Corporation.



• Net weight (2.2 lb = 1 kg)
• 3 lb 9 oz (3.563 lb) / 1.617 kg

• Author
• Model page created by Lester Troeckler. See "Data change" for further contributors.
