2182 kHz Watchkeeping Receiver Sailor R501
SP Radio (S.P.), Sailor Marineradio; Aalborg
- Country
- Denmark
- Manufacturer / Brand
- SP Radio (S.P.), Sailor Marineradio; Aalborg
- Year
- 1990 ??
- Category
- Commercial Receiver (may include amateur bands)
- Radiomuseum.org ID
- 308446
-
- Brand: Sailor
- Number of Transistors
- Semiconductors present.
- Semiconductors
- Main principle
- Superhet with RF-stage; ZF/IF 334,582 kHz
- Wave bands
- Short Wave (SW only)
- Power type and voltage
- Line / Storage batteries (perhaps also batteries) / 24; 110; 220 Volt
- Loudspeaker
- Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 5.5 cm = 2.2 inch
- Power out
- 1 W (unknown quality)
- Material
- Metal case
- from Radiomuseum.org
- Model: 2182 kHz Watchkeeping Receiver Sailor R501 - SP Radio S.P., Sailor
- Shape
- Miscellaneous shapes - described under notes.
- Dimensions (WHD)
- 230 x 150 x 163 mm / 9.1 x 5.9 x 6.4 inch
- Notes
-
Seefunkempfänger für die Grenzwellen-Notfrequenz 2182 kHz, empfängt A2, A2H, A3 und A3H. Der Empfänger wird automatisch aktiviert bei Empfang eines Zweiton-Autoalarm-Signals oder eines Navigations-Warnsignals. Für Wandmontage mit spezieller Halterung.
- Net weight (2.2 lb = 1 kg)
- 3 kg / 6 lb 9.7 oz (6.608 lb)
- Mentioned in
- - - Manufacturers Literature (Instructionbook for 2182 kHz Watchkeeping Receiver R501)
- Author
- Model page created by Siegfried Droese. See "Data change" for further contributors.
