• Country
• Denmark

• Manufacturer / Brand
• SP Radio (S.P.), Sailor Marineradio; Aalborg

• Year
• 1972 ?

• Category
• Commercial Receiver (may include amateur bands)

• Radiomuseum.org ID
• 114568

• • Brand: Sailor

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Transistors
• 32

• Semiconductors

• Main principle
• Superhet with RF-stage; ZF/IF 600 kHz

• Wave bands
• Broadcast, Long Wave and Short Wave.

• Power type and voltage
• Line / Batteries (any type) / 110/220; 12/24 Volt

• Loudspeaker
• - For headphones or amp.

• Power out
• 5 W (unknown quality)

• Material
• Metal case

• from Radiomuseum.org
• Model: Sailor R106 - SP Radio S.P., Sailor

• Shape
• Tablemodel, with any shape - general.

• Dimensions (WHD)
• 492 x 232 x 220 mm / 19.4 x 9.1 x 8.7 inch

• Notes
• Maritime telephony and direction finding receiver, 150-350 / 300-535 / 700-1650 / 1600 - 4200 kHz and 35 crystal controlled channels including 2182 kHz emergency channel, AM, SSB, CW.
  Very similar to R104 but with three fixed frequency modules.

• Net weight (2.2 lb = 1 kg)
• 15 kg / 33 lb 0.6 oz (33.04 lb)

• Literature/Schematics (1)
• -- Schematic

• Author
• Model page created by Martin Bösch. See "Data change" for further contributors.
