13C505 Ch= 22V244B
Sparks-Withington Co., (Sparton); Jackson, Michigan
- Country
- United States of America (USA)
- Manufacturer / Brand
- Sparks-Withington Co., (Sparton); Jackson, Michigan
- Year
- 1955 ?
- Category
- Television Receiver (TV) or Monitor
- Radiomuseum.org ID
- 187042
By courtesy of guest Scott Blayden, USA.
By courtesy of guest Scott Blayden, USA.
By courtesy of guest Scott Blayden, USA.
By courtesy of guest Scott Blayden, USA.
By courtesy of guest Scott Blayden, USA.
By courtesy of guest Scott Blayden, USA.
By courtesy of guest Scott Blayden, USA.
By courtesy of guest Scott Blayden, USA.
By courtesy of guest Scott Blayden, USA.
By courtesy of guest Scott Blayden, USA.
By courtesy of guest Scott Blayden, USA.
By courtesy of guest Scott Blayden, USA.
By courtesy of guest Scott Blayden, USA.
By courtesy of guest Scott Blayden, USA.
Click on the schematic thumbnail to request the schematic as a free document.
- Number of Tubes
- 23
- Valves / Tubes
- 6BQ7A 6J6 6CB6 6CB6 6CB6 12BY7 6AU6 6AU6 6AU6 6AL5 6AT6 6V6GT 12AU7 6SN7GTA 6BQ6GT 6AL5 6SN7GTA 6CD6G 6AU4GT 1B3GT 5Y3GT 5U4G 24TP4
- Main principle
- Superhet with RF-stage
- Wave bands
- VHF incl. FM and/or UHF (see notes for details)
- Power type and voltage
- Alternating Current supply (AC) / 60 Hz, 117V = 110 -120 Volt
- Loudspeaker
- 2 Loudspeakers
- Material
- Wooden case
- from Radiomuseum.org
- Model: 13C505 Ch= 22V244B - Sparks-Withington Co., Sparton
- Shape
- Console, Lowboy (legs < 50 %).
- Notes
-
Sparton model 13C505 is a 24” b/w TV with US standard VHF tuner channels 2 thru 13.
Equipped with chassis 22V244B, VHF tuner FD92102 and picture tube 24CP4A.
- Literature/Schematics (4)
- Photofact Folder, Howard W. SAMS (Set 296, Date 11/55, Folder 10)
- Author
- Model page created by Ernst Erb. See "Data change" for further contributors.
- Other Models
-
Here you find 818 models, 369 with images and 764 with schematics for wireless sets etc. In French: TSF for Télégraphie sans fil.
All listed radios etc. from Sparks-Withington Co., (Sparton); Jackson, Michigan
