- Country
- United States of America (USA)
- Manufacturer / Brand
- Sparks-Withington Co., (Sparton); Jackson, Michigan
- Year
- 1932
- Category
- Broadcast Receiver - or past WW2 Tuner
- Radiomuseum.org ID
- 58521
Click on the schematic thumbnail to request the schematic as a free document.
- Number of Tubes
- 8
- Main principle
- Superhet with RF-stage; ZF/IF 172.5 kHz; 2 AF stage(s); Screengrid 1926-1935
- Tuned circuits
- 7 AM circuit(s)
- Wave bands
- Broadcast only (MW).
- Power type and voltage
- Alternating Current supply (AC) / 100-130 Volt
- Loudspeaker
- Electro Magnetic Dynamic LS (moving-coil with field excitation coil)
- Material
- Wooden case
- from Radiomuseum.org
- Model: Sparton 14 - Sparks-Withington Co., Sparton
- Shape
- Console, Lowboy (legs < 50 %).
- Notes
-
The Sparton model 14 has bandfilter input circuits. This radio model can not be earlier than 1932, because of some tubes used.
- Price in first year of sale
- 69.00 $
- External source of data
- Ernst Erb
- Source of data
- Radio Collector`s Guide 1921-1932
- Circuit diagram reference
- Rider's Perpetual, Volume 4 = ca. 1934 and before
- Mentioned in
- The Radio Collector's Directory and Price Guide 1921 - 1965 (Rider's 2-6, 2-7)
- Literature/Schematics (1)
- Sparton Radio Service Manual (Sparton Manual 1, Bulletin 45-1, 2, Bulletin 31-3, 4)
