Sparton 16AW Allwave
Sparks-Withington Co., (Sparton); Jackson, Michigan
- Country
- United States of America (USA)
- Manufacturer / Brand
- Sparks-Withington Co., (Sparton); Jackson, Michigan
- Year
- 1931/1932
- Category
- Broadcast Receiver - or past WW2 Tuner
- Radiomuseum.org ID
- 58544
Scanned from the Radio Retailing.
Click on the schematic thumbnail to request the schematic as a free document.
- Number of Tubes
- 12
- Main principle
- Superhet with RF-stage; ZF/IF 172.5 kHz; 1 AF stage(s)
- Tuned circuits
- 8 AM circuit(s)
- Wave bands
- Wave Bands given in the notes.
- Power type and voltage
- Alternating Current supply (AC) / 3 taps: 100-130 Volt
- Loudspeaker
- Permanent or electro-dynamic (moving coil), system not known yet.
- Material
- Wooden case
- from Radiomuseum.org
- Model: Sparton 16AW Allwave - Sparks-Withington Co., Sparton
- Shape
- Console with any shape - in general
- Notes
-
Medium wave receiver with bandfilter input circuits. The integrated shortwave converter model 60 adds 4 SW bands: 1.5 to 25.5 MHz.
Ad from 1932 for Sparks-Withington Co., Jackson, Michigan: The ad features a Model 16 A W, a deluxe 12-tube Superheterodyne in a beautiful console " of characteristic Sparton richness." Two separate tuning controls, Long or short wave reception, Super-sonne Chassis, Auto Volume Control, Tone, and Static Control, Phono Pick-up Jack and all other latest Sparton features. Also shown in a smaller inset photo is the Model 60 Short wave converter.
- Price in first year of sale
- 155.00 $
- External source of data
- Ernst Erb
- Source of data
- Radio Collector`s Guide 1921-1932
- Circuit diagram reference
- Rider's Perpetual, Volume 2 = 1932 (Models 1931/1932)
- Mentioned in
- Rider's 2-11
