23A205B Ch= 22V244B
Sparks-Withington Co., (Sparton); Jackson, Michigan
- Country
- United States of America (USA)
- Manufacturer / Brand
- Sparks-Withington Co., (Sparton); Jackson, Michigan
- Year
- 1955 ?
- Category
- Television Receiver (TV) or Monitor
- Radiomuseum.org ID
- 187046
SAMS Photofact
Click on the schematic thumbnail to request the schematic as a free document.
- Number of Tubes
- 23
- Valves / Tubes
- 6BQ7A 6J6 6CB6 6CB6 6CB6 12BY7 6AU6 6AU6 6AU6 6AL5 6AT6 6V6GT 12AU7 6SN7GTA 6BQ6GT 6AL5 6SN7GTA 6CD6G 6AU4GT 1B3GT 5Y3GT 5U4G 24TP4
- Main principle
- Superhet with RF-stage
- Wave bands
- VHF incl. FM and/or UHF (see notes for details)
- Power type and voltage
- Alternating Current supply (AC) / 60 Hz, 117V = 110 -120 Volt
- Loudspeaker
- 2 Loudspeakers
- Material
- Wooden case
- from Radiomuseum.org
- Model: 23A205B Ch= 22V244B - Sparks-Withington Co., Sparton
- Shape
- Console with any shape - in general
- Notes
-
Sparton model 23A205B is a 24” b/w TV with US standard VHF tuner channels 2 thru 13.
Equipped with chassis 22V244B, VHF tuner FD92102 and picture tube 24CP4A.
- Literature/Schematics (4)
- Photofact Folder, Howard W. SAMS (Set 296, Date 11/55, Folder 10)
