Sparton 26 Broadcast
Sparks-Withington Co., (Sparton); Jackson, Michigan
- Country
- United States of America (USA)
- Manufacturer / Brand
- Sparks-Withington Co., (Sparton); Jackson, Michigan
- Year
- 1931
- Category
- Broadcast Receiver - or past WW2 Tuner
- Radiomuseum.org ID
- 58563
Click on the schematic thumbnail to request the schematic as a free document.
- Number of Tubes
- 10
- Main principle
- Superhet with RF-stage; ZF/IF 172.5 kHz; 1 AF stage(s)
- Tuned circuits
- 10 AM circuit(s)
- Wave bands
- Broadcast only (MW).
- Power type and voltage
- Alternating Current supply (AC)
- Loudspeaker
- Electro Magnetic Dynamic LS (moving-coil with field excitation coil)
- Material
- Wooden case
- from Radiomuseum.org
- Model: Sparton 26 Broadcast - Sparks-Withington Co., Sparton
- Shape
- Console, Highboy (legs > 50 %).
- Notes
-
4 legged highboy with stretcher base.
Push-pull audio amplifier.
- Price in first year of sale
- 165.00 $
- External source of data
- Ernst Erb
- Source of data
- Radio Collector`s Guide 1921-1932
- Circuit diagram reference
- Rider's Perpetual, Volume 2 = 1932 (Models 1931/1932)
- Mentioned in
- The Radio Collector's Directory and Price Guide 1921 - 1965 (Rider's 2-14, 2-15)
- Literature/Schematics (1)
- Pre-War Consoles
- Literature/Schematics (2)
- Sparton Radio Service Manual (Sparton Manual 1, Bulletin 37-1, 2 Bulletin 33-3, 4)
