4965 Ch= 23TB10
Sparks-Withington Co., (Sparton); Jackson, Michigan
- Country
- United States of America (USA)
- Manufacturer / Brand
- Sparks-Withington Co., (Sparton); Jackson, Michigan
- Year
- 1952 ?
- Category
- Television Receiver (TV) or Monitor
- Radiomuseum.org ID
- 353510
Click on the schematic thumbnail to request the schematic as a free document.
- Number of Tubes
- 27
- Valves / Tubes
- 6BH6 6AG5 6C4 6BH6 6BH6 6BH6 6BH6 6AL5 6AU6 6AK6 12AU7 6AU6 6AU6 6AU6 6AL5 6AT6 6V6GT 6SN7GT 6V6GT 6AL5 12AU7 6BG6 5V4G 6SN7GT 1B3GT 5U4G 16AP4A
- Main principle
- Superhet with RF-stage
- Wave bands
- Wave Bands given in the notes.
- Power type and voltage
- Alternating Current supply (AC) / 60 Hz, 117V = 110 -120 Volt
- Loudspeaker
- Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil)
- Material
- Wooden case
- from Radiomuseum.org
- Model: 4965 Ch= 23TB10 - Sparks-Withington Co., Sparton
- Shape
- Console with any shape - in general
- Notes
-
Sparton model 4965 is a 16” b/w TV with US standard VHF tuner channels 2 thru 13.
Equipped with chassis 23TB10, VHF tuner AD93151-2 and picture tube 16AP4A.
