- Country
- United States of America (USA)
- Manufacturer / Brand
- Sparks-Withington Co., (Sparton); Jackson, Michigan
- Year
- 1933
- Category
- Broadcast Receiver - or past WW2 Tuner
- Radiomuseum.org ID
- 58785
Click on the schematic thumbnail to request the schematic as a free document.
- Number of Tubes
- 5
- Main principle
- Superheterodyne (common); ZF/IF 456 kHz; 2 AF stage(s)
- Tuned circuits
- 6 AM circuit(s)
- Wave bands
- Broadcast and Short Wave (SW).
- Power type and voltage
- AC/DC-set / 115 Volt
- Loudspeaker
- Electro Magnetic Dynamic LS (moving-coil with field excitation coil)
- Material
- Wooden case
- from Radiomuseum.org
- Model: Sparton 62 - Sparks-Withington Co., Sparton
- Shape
- Tablemodel, with any shape - general.
- Notes
-
147 ohm resistance power cord.
- Price in first year of sale
- 30.00 $
- External source of data
- Ernst Erb
- Source of data
- Radio Collector`s Guide 1921-1932
- Circuit diagram reference
- Rider's Perpetual, Volume 4 = ca. 1934 and before
- Mentioned in
- The Radio Collector's Directory and Price Guide 1921 - 1965 (Rider's 4-11, Rider's Changes 7-15)
- Literature/Schematics (1)
- Sparton Radio Service Manual (Sparton Manual 1, Bulletin 57-1 to -5)
- Literature/Schematics (3)
- Radio Retailing (Radio & Television R.) (August 1933 page 28.)
