Sparton 4941TV
Sparks-Withington Co., (Sparton); Jackson, Michigan
- Country
- United States of America (USA)
- Manufacturer / Brand
- Sparks-Withington Co., (Sparton); Jackson, Michigan
- Year
- 1949
- Category
- Television- and Radio Receiver, perh. also + Rec. etc. (TV Radio)
- Radiomuseum.org ID
- 222442
Click on the schematic thumbnail to request the schematic as a free document.
- Number of Tubes
- 37
- Valves / Tubes
- 6BH6 6AG5 6C4 6BH6 6BH6 6BH6 6BH6 6AL5 6AU6 6AK6 6AL5 6AU6 6AU6 6AU6 6AL5 6AT6 6V6 6J6 6SN7 6V6 6AL5 12AU7 6L6 5V4 6SN7 1B3 5U4 6BA6 6BE6 7A7 7AG7 7AG7 7AG7 6AL5 7B6 7B5 5Y3 10BP4
- Main principle
- Superheterodyne (common)
- Wave bands
- Wave Bands given in the notes.
- Details
- Record Player (perh.Changer)
- Power type and voltage
- Alternating Current supply (AC) / 117 Volt
- Loudspeaker
- Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil)
- Material
- Wooden case
- from Radiomuseum.org
- Model: Sparton 4941TV - Sparks-Withington Co., Sparton
- Shape
- Console, Lowboy (legs < 50 %).
- Dimensions (WHD)
- 660 x 813 x 381 mm / 26 x 32 x 15 inch
- Source of data
- Photofact Folder, Howard W. SAMS
- Mentioned in
- Volume 7 Set #64 Folder 4912-11 06/1949
- Author
- Model page created by Arpad Roth † 27.3.17. See "Data change" for further contributors.
