Sparton 5007X Ch. 25TK10A
Sparks-Withington Co., (Sparton); Jackson, Michigan
- Country
- United States of America (USA)
- Manufacturer / Brand
- Sparks-Withington Co., (Sparton); Jackson, Michigan
- Year
- 1951 ?
- Category
- Television Receiver (TV) or Monitor
- Radiomuseum.org ID
- 173883
Click on the schematic thumbnail to request the schematic as a free document.
- Number of Tubes
- 25
- Valves / Tubes
- 6BH6 6AG5 6C4 6BJ6 6BJ6 6BH6 6BJ6 6AL5 6AH6 6AU6 6AU6 6AU6 6T8 6V6GT 12AU7 6SN7GT 6V6GT 6AL5 6SN7GT 6BG6G 6W4GT 1X2 6AX5 5U4G 12LP4
- Main principle
- Superhet with RF-stage
- Wave bands
- VHF incl. FM and/or UHF (see notes for details)
- Power type and voltage
- Alternating Current supply (AC) / 60 Hz, 117V = 110 -120 Volt
- Loudspeaker
- Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil)
- Material
- Wooden case
- from Radiomuseum.org
- Model: Sparton 5007X Ch. 25TK10A - Sparks-Withington Co., Sparton
- Shape
- Tablemodel, with any shape - general.
- Notes
- Sparton 5007X, Ch. 25TK10A; b/w round CRT TV with US FCC standard VHF turret tuner.
- Mentioned in
- Photofact Folder, Howard W. SAMS (Set 121, Folder 13, 1-1951)
- Author
- Model page created by a member from A. See "Data change" for further contributors.
