• Country
• United States of America (USA)

• Manufacturer / Brand
• Sparks-Withington Co., (Sparton); Jackson, Michigan

• Year
• 1926

• Category
• Broadcast Receiver - or past WW2 Tuner

• Radiomuseum.org ID
• 58970

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Tubes
• 6

• Valves / Tubes
• 401_McCullough 401_McCullough 401_McCullough 401_McCullough 401_McCullough BH

• Main principle
• TRF without regeneration

• Tuned circuits
• 3 AM circuit(s)

• Wave bands
• Broadcast only (MW).

• Power type and voltage
• Alternating Current supply (AC)

• Material
• Wooden case

• from Radiomuseum.org
• Model: Sparton AC-5 [without Selectifier] - Sparks-Withington Co., Sparton

• Shape
• Tablemodel, Box - most often with Lid (NOT slant panel).

• Price in first year of sale
• 260.00 $

• External source of data
• Ernst Erb

• Source of data
• Radio Collector`s Guide 1921-1932

• Mentioned in
• - - Manufacturers Literature

• Literature/Schematics (1)
• Sparton Radio Service Manual (Sparton Manual 1, Bulletin 2-1,2, Bulletin 1-3)
