• Country
• Canada

• Manufacturer / Brand
• Sparton of Canada; London, ON

• Year
• 1957 ?

• Category
• Broadcast Receiver - or past WW2 Tuner

• Radiomuseum.org ID
• 300821

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Tubes
• 7

• Valves / Tubes
• 6BE6 6BA6 6AV6 6AU6 6V6GT 6V6GT 5Y3GT

• Main principle
• Superheterodyne (common); ZF/IF 455 kHz; 3 AF stage(s)

• Tuned circuits
• 6 AM circuit(s)

• Wave bands
• Broadcast only (MW).

• Details
• Record Player (perh.Changer)

• Power type and voltage
• Alternating Current supply (AC) / 60 Hz, 117 Volt

• Loudspeaker
• 3 Loudspeakers

• from Radiomuseum.org
• Model: 7G1-P - Sparton of Canada; London, ON

• Notes

• The Sparton model 7G1-P is a 7-tube radio with phonograph. Has bass and treble controls. With woofer and two tweeter P.M speakers.

• Literature/Schematics (1)
• Radio College of Canada (RCC) (1957 Supplement 41)

• Author
• Model page created by Tom Seeger. See "Data change" for further contributors.
