- Country
- Canada
- Manufacturer / Brand
- Sparton of Canada; London, ON
- Year
- 1948/1949
- Category
- Broadcast Receiver - or past WW2 Tuner
- Radiomuseum.org ID
- 180152
Click on the schematic thumbnail to request the schematic as a free document.
- Number of Tubes
- 10
- Main principle
- Superhet with RF-stage; ZF/IF 10700 / 455 kHz
- Tuned circuits
- 9 AM circuit(s)
- Wave bands
- Broadcast (BC) and FM or UHF.
- Power type and voltage
- Alternating Current supply (AC) / 117 Volt
- Loudspeaker
- Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil)
- from Radiomuseum.org
- Model: 10549 - Sparton of Canada; London, ON
- Notes
- Built in loop antenna. Speaker : 6,9 or 12 inch.
- Circuit diagram reference
- Radio College of Canada
- Literature/Schematics (1)
- Canada schematics Sparton page 128
- Author
- Model page created by Dirk Taekels. See "Data change" for further contributors.
