- Country
- Canada
- Manufacturer / Brand
- Sparton of Canada; London, ON
- Year
- 1937/1938
- Category
- Broadcast Receiver - or past WW2 Tuner
- Radiomuseum.org ID
- 179412
Click on the schematic thumbnail to request the schematic as a free document.
- Number of Tubes
- 4
- Main principle
- Superheterodyne (common); ZF/IF 456 kHz
- Tuned circuits
- 6 AM circuit(s)
- Wave bands
- Broadcast only (MW).
- Power type and voltage
- Alternating Current supply (AC) / 115 Volt
- Loudspeaker
- Electro Magnetic Dynamic LS (moving-coil with field excitation coil)
- Material
- Wooden case
- from Radiomuseum.org
- Model: 48K - Sparton of Canada; London, ON
- Circuit diagram reference
- Radio College of Canada
- Literature/Schematics (1)
- Canada Schematics Sparton page 52
- Author
- Model page created by Dirk Taekels. See "Data change" for further contributors.
