- Country
- United States of America (USA)
- Manufacturer / Brand
- Spiegel Inc. (Continental); Chicago
- Year
- 1947
- Category
- Broadcast Receiver - or past WW2 Tuner
- Radiomuseum.org ID
- 59441
SAMS Photofact
Click on the schematic thumbnail to request the schematic as a free document.
- Number of Tubes
- 5
- Main principle
- Superhet with RF-stage; ZF/IF 455 kHz; 2 AF stage(s)
- Tuned circuits
- 6 AM circuit(s)
- Wave bands
- Broadcast only (MW).
- Power type and voltage
- AC/DC-set / 110 - 120 Volt
- Loudspeaker
- Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 4.75 inch = 12.1 cm
- Material
- Plastics (no bakelite or catalin)
- from Radiomuseum.org
- Model: 5003 - Spiegel Inc. Continental;
- Shape
- Tablemodel, with any shape - general.
- Notes
- Photofact see under Trade name: Aircastle.
- External source of data
- Ernst Erb
- Source of data
- The Radio Collector's Directory and Price Guide 1921 - 1965
- Circuit diagram reference
- Rider's Perpetual, Volume 17 = 1948 and before
- Mentioned in
- Collector's Guide to Antique Radios 4. Edition
- Literature/Schematics (1)
- Photofact Folder, Howard W. SAMS (Set 20, Folder 4710-1)
- Other Models
-
Here you find 1279 models, 552 with images and 1043 with schematics for wireless sets etc. In French: TSF for Télégraphie sans fil.
All listed radios etc. from Spiegel Inc. (Continental); Chicago
