Air Castle WP103 Ch= TC
Spiegel Inc. (Continental); Chicago
- Country
- United States of America (USA)
- Manufacturer / Brand
- Spiegel Inc. (Continental); Chicago
- Year
- 1939
- Category
- Broadcast Receiver - or past WW2 Tuner
- Radiomuseum.org ID
- 298195
- Number of Tubes
- 5
- Main principle
- Superheterodyne (common); ZF/IF 456 kHz
- Tuned circuits
- 6 AM circuit(s)
- Wave bands
- Broadcast only (MW).
- Power type and voltage
- Alternating Current supply (AC) / 105 - 115 Volt
- Loudspeaker
- Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 5 inch = 12.7 cm
- Material
- Wooden case
- from Radiomuseum.org
- Model: Air Castle WP103 Ch= TC - Spiegel Inc. Continental;
- Shape
- Tablemodel without push buttons, Mantel/Midget/Compact up to 14
- Dimensions (WHD)
- 13.25 x 8 x 6.25 inch / 337 x 203 x 159 mm
- Notes
-
Model Differences WP102 For AC operation WP103 For AC operation with all-wave doublet antenna system included WP204 Battery operated WP205 Battery operated with all-wave doublet antenna system included WP206 6-volt battery included WP207 6-volt battery and all-wave doublet antenna system included
- Price in first year of sale
- 19.95 $
- Mentioned in
- Spiegel Catalogs (Aircastle) (Spring/Summer 1939, No. 147, page 352.)
- Literature/Schematics (1)
- Rider's Perpetual, Volume 12 = ca. 1941 and before (Page 12-1)
- Author
- Model page created by Noemi Erb. See "Data change" for further contributors.
