Aircastle Solid State 8 Band 10-561

Spiegel Inc. (Continental); Chicago

Data
Forum
Pictures
Collections

  • Year
  • 1970 ??
  • Category
  • Broadcast Receiver - or past WW2 Tuner
  • Radiomuseum.org ID
  • 305502

 Technical Specifications

  • Number of Transistors
  • Semiconductors present.
  • Semiconductors
  • Main principle
  • Superheterodyne (common)
  • Wave bands
  • Broadcast, Long Wave, more than 2 x SW plus FM or UHF.
  • Power type and voltage
  • Line / Batteries (any type) / 120 or 4 x D 1.5 Volt
  • Loudspeaker
  • Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil)
  • Material
  • Plastics (no bakelite or catalin)
  • from Radiomuseum.org
  • Model: Aircastle Solid State 8 Band 10-561 - Spiegel Inc. Continental;
  • Shape
  • Portable set > 8 inch (also usable without mains)
  • Dimensions (WHD)
  • 14 x 10 x 6 inch / 356 x 254 x 152 mm
  • Notes

  • This model is very similar to the Lloyd's 9N11B-120A except that the Lloyd's does not have a dial cover.  Also very similar to Koyo KTR-1664 BFO.  Koyo is believed to be the manufacturer and they also may have made similar models branded by Midland, Truetone, and Commodore.

    Made in Japan

  • Author
  • Model page created by Aldo Andreani. See "Data change" for further contributors.
