Air Castle TP2054 Ch= 175E
Spiegel Inc. (Continental); Chicago
- Country
- United States of America (USA)
- Manufacturer / Brand
- Spiegel Inc. (Continental); Chicago
- Year
- 1938
- Category
- Broadcast Receiver - or past WW2 Tuner
- Radiomuseum.org ID
- 59716
Click on the schematic thumbnail to request the schematic as a free document.
- Number of Tubes
- 8
- Main principle
- Superheterodyne (common); ZF/IF 456 kHz
- Tuned circuits
- 6 AM circuit(s)
- Wave bands
- Broadcast, Short Wave(s) and Police.
- Power type and voltage
- Alternating Current supply (AC) / 105 - 115 Volt
- Loudspeaker
- Electro Magnetic Dynamic LS (moving-coil with field excitation coil) / Ø 8 inch = 20.3 cm
- Material
- Wooden case
- from Radiomuseum.org
- Model: Air Castle TP2054 Ch= 175E - Spiegel Inc. Continental;
- Shape
- Console with Push Buttons.
- Dimensions (WHD)
- 21.5 x 40 x 11 inch / 546 x 1016 x 279 mm
- Notes
-
Automatic electric tuner. Built-in Pennwood clock.
- Price in first year of sale
- 59.95 $
- External source of data
- Ernst Erb
- Circuit diagram reference
- Rider's Perpetual, Volume 12 = ca. 1941 and before
- Mentioned in
- Spiegel Catalogs (Aircastle) (Spring/Summer 1938, No. 145, page 338.)
- Literature/Schematics (1)
- Riders 12-13 , 12-14
