Stratofon SF12 Super

Stabo; Hildesheim

Data
Forum
Pictures
Collections

  • Year
  • 1977
  • Category
  • Citizen Band Equipment
  • Radiomuseum.org ID
  • 337380

Click on the schematic thumbnail to request the schematic as a free document.

 Technical Specifications

  • Number of Transistors
  • 19
  • Main principle
  • Transceiver; ZF/IF 455 kHz
  • Wave bands
  • Short Wave (SW only)
  • Power type and voltage
  • Alternating Current supply (AC) / 220 Volt
  • Loudspeaker
  • Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 7 cm = 2.8 inch
  • Power out
  • 2 W (undistorted)
  • Material
  • Metal case
  • from Radiomuseum.org
  • Model: Stratofon SF12 Super - Stabo; Hildesheim
  • Shape
  • Tablemodel without push buttons, Mantel/Midget/Compact up to 14
  • Dimensions (WHD)
  • 240 x 64 x 0 mm / 9.4 x 2.5 x 0 inch
  • Notes

  • Einfachsuper-Basisstation für CB-Funk

    12-Kanäle, AM, Quarz-Synthesizer, NF-Verstärker mit dem IC BA511, zwei Einbauinstrumente,  eines für SWR und Modulation, anderes für S-Wert und Ausgangsleistung. Sendeleistung 0,5 W. FTZ-Prüfnummer KF-048/77.



  • Net weight (2.2 lb = 1 kg)
  • 3 kg / 6 lb 9.7 oz (6.608 lb)
  • Mentioned in
  • -- Original prospect or advert
  • Author
  • Model page created by Alois Wolf. See "Data change" for further contributors.
