• Country
• Germany

• Manufacturer / Brand
• Stabo; Hildesheim

• Year
• 2000 ??

• Category
• Commercial Transmitter & Receiver (TRX not Amateur)

• Radiomuseum.org ID
• 261992

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Transistors
• Semiconductors present.

• Semiconductors

• Main principle
• Transceiver

• Wave bands
• VHF incl. FM and/or UHF (see notes for details)

• Power type and voltage
• Storage and/or dry batteries / 7,2 Volt

• Loudspeaker
• Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil)

• Power out
• 0.5 W (max.)

• Material
• Plastics (no bakelite or catalin)

• from Radiomuseum.org
• Model: VHF-Handfunkgerät freetalk 2 Art.-Nr. 20211 - Stabo; Hildesheim

• Shape
• Miscellaneous shapes - described under notes.

• Dimensions (WHD)
• 58 x 103 x 26.5 mm / 2.3 x 4.1 x 1 inch

• Notes

• VHF-Handfunkgerät, 3 Kanäle 149,025-149,050MHz, anmelde und gebührenfrei,

  Sendeleistung 500mW,

  CTCSS und DCS Pilotton,

  Anschlüsse für Mikro und Hörer,

  eingebauter Vibrationsmelder,

  Betrieb mit Batterien oder Akku,

  Antennenbuchse SMA-Female.

• Net weight (2.2 lb = 1 kg)
• 0.2 kg / 0 lb 7 oz (0.441 lb)

• Mentioned in
• -- Original prospect or advert

• Author
• Model page created by a member from D. See "Data change" for further contributors.
