Darling

• Country
• Hungary

• Manufacturer / Brand
• Standard; Budapest

• Year
• 1935/1936

• Category
• Broadcast Receiver - or past WW2 Tuner

• Radiomuseum.org ID
• 96578

• Picture
• Schematics

Previous Next

Previous Next

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Tubes
• 3

• Valves / Tubes
• AF7 AL1 AZ1

• Main principle
• TRF (Tuned-Radio-Frequency but use of regeneration unknown)

• Wave bands
• Broadcast (MW) and Long Wave.

• Power type and voltage
• Alternating Current supply (AC) / 120-240 Volt

• Loudspeaker
• Electro Magnetic Dynamic LS (moving-coil with field excitation coil)

• Material
• Wooden case

• from Radiomuseum.org
• Model: Darling - Standard; Budapest

• Shape
• Tablemodel, high profile (upright - NOT Cathedral nor decorative).

• Price in first year of sale
• 165.00 pengö

• Mentioned in
• Rádiókészülékek Kapcsolásai 1936-56

• Author
• Model page created by Gabriel Toth. See "Data change" for further contributors.

• Other Models

• Here you find 156 models, 147 with images and 88 with schematics for wireless sets etc. In French: TSF for Télégraphie sans fil.
