• Country
• Germany

• Manufacturer / Brand
• Stassfurter Licht- und Kraftwerke AG; Staßfurt (Staßfurter)

• Year
• 1937/1938

• Category
• Broadcast Receiver - or past WW2 Tuner

• Radiomuseum.org ID
• 4987

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Tubes
• 9

• Valves / Tubes
• AF3 AH1 AC2 AF3 AM2 AB2 AC2 AL5 RGN2004

• Main principle
• Superhet with RF-stage; ZF/IF 486 kHz

• Tuned circuits
• 7 AM circuit(s)

• Wave bands
• Broadcast, Long Wave and Short Wave.

• Power type and voltage
• Alternating Current supply (AC) / 110; 125; 150; 220; 240 Volt

• Loudspeaker
• 2 Loudspeakers

• Material
• Wooden case

• from Radiomuseum.org
• Model: Imperial 98W - Stassfurter Licht- und

• Shape
• Tablemodel, low profile (big size).

• Dimensions (WHD)
• 650 x 410 x 310 mm / 25.6 x 16.1 x 12.2 inch

• Notes
• Variable Bandbreite.

• Net weight (2.2 lb = 1 kg)
• 22.3 kg / 49 lb 1.9 oz (49.119 lb)

• Price in first year of sale
• 398.00 RM

• Source of data
• Handbuch WDRG 1937 / Radiokatalog Band 1, Ernst Erb

• Circuit diagram reference
• Lange+Schenk+FS-Röhrenbestückung

• Mentioned in
• Funkgeschichte der GFGF (9076)

• Picture reference
• Das Modell ist im «Radiokatalog» (Erb) abgebildet.
