• Country
• Germany

• Manufacturer / Brand
• Staudigl, Rudolf, Elektrotechnische Fabrik; Trautheim (Darmstadt 2)

• Year
• 1950/1951

• Category
• Broadcast Receiver - or past WW2 Tuner

• Radiomuseum.org ID
• 17069

• • Brand: Elektrotechnische Fabrik Staudigl

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Tubes
• 6

• Valves / Tubes
• ECH4 ECH4 EBF11 EL12/325 EM4 AZ4

• Main principle
• Superheterodyne (common); ZF/IF 473 kHz

• Tuned circuits
• 6 AM circuit(s)

• Wave bands
• Broadcast, Long Wave and Short Wave.

• Details
• Record Player (not changer)

• Power type and voltage
• Alternating Current supply (AC) / 110/220 Volt

• Loudspeaker
• Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 25 cm = 9.8 inch

• Material
• Wooden case

• from Radiomuseum.org
• Model: Studio I 369W - Staudigl, Rudolf,

• Shape
• Tablemodel, low profile (big size).

• Dimensions (WHD)
• 630 x 400 x 360 mm / 24.8 x 15.7 x 14.2 inch

• Notes
• Kontroll-Lautsprecher eingebaut, Betriebs-Lautsprecher auf separater Schallwand 850×850 mm, 18 kg. Plattenspieler mit Kristall-System; Tonfilmanschluss-Saugspannung etwa 115 V; Mikrofon- und Magnetton-Anschluss.

• Net weight (2.2 lb = 1 kg)
• 24 kg / 52 lb 13.8 oz (52.863 lb)

• Price in first year of sale
• 780.00 DM

• External source of data
• E. Erb 3-907007-36-0

• Source of data
• Kat.d. Rundf.Gr.Handel 1950/51 / Radiokatalog Band 2, Ernst Erb

• Circuit diagram reference
• Lange-Nowisch

• Mentioned in
• Funkschau (5016)

• Literature/Schematics (1)
• -- Schematic

• Picture reference
• Das Gerät ist im Doppelband "Historische Radios" von Günther Abele abgebildet.
