259E Ch= D259
Standard Telephones and Cables Pty, Ltd (STC), Sydney
- Country
- Australia
- Manufacturer / Brand
- Standard Telephones and Cables Pty, Ltd (STC), Sydney
- Year
- 1947/1948
- Category
- Broadcast Receiver - or past WW2 Tuner
- Radiomuseum.org ID
- 349206
- Number of Tubes
- 5
- Main principle
- Superheterodyne (common); 2 AF stage(s)
- Tuned circuits
- 6 AM circuit(s)
- Wave bands
- Broadcast and Short Wave (SW).
- Power type and voltage
- Alternating Current supply (AC) / 40-60 Hz, 230 - 250 Volt
- Loudspeaker
- Electro Magnetic Dynamic LS (moving-coil with field excitation coil) / Ø 8 inch = 20.3 cm
- Material
- Wooden case
- from Radiomuseum.org
- Model: 259E Ch= D259 - Standard Telephones and Cables
- Shape
- Tablemodel, low profile (big size).
- Dimensions (WHD)
- 22 x 15 x 11 inch / 559 x 381 x 279 mm
- Price in first year of sale
- 36.50 AUS £
- Mentioned in
- Radio Electrical WEEKLY (New Products, 6/10/1947.)
- Literature/Schematics (1)
- -- Original-techn. papers. (STC Radio Service Bulletin No. 32, Feb 1948.)
- Author
- Model page created by Stuart Irwin. See "Data change" for further contributors.
