Conductor
Steelphon; Torino
- Country
- Italy
- Manufacturer / Brand
- Steelphon; Torino
- Year
- 1970 ??
- Category
- Audio Amplifier or -mixer
- Radiomuseum.org ID
- 267457
- Number of Tubes
- 7
- Main principle
- Audio-Amplification
- Wave bands
- - without
- Details
- Guitar Amplifier
- Power type and voltage
- Alternating Current supply (AC) / 110; 125; 140; 160; 220; 280 Volt
- Loudspeaker
- - This model requires external speaker(s).
- Power out
- 40 W (undistorted)
- Material
- Wooden case
- from Radiomuseum.org
- Model: Conductor - Steelphon; Torino
- Shape
- Tablemodel, low profile (big size).
- Dimensions (WHD)
- 460 x 240 x 230 mm / 18.1 x 9.4 x 9.1 inch
- Notes
-
Four inputs for guitar, organ and bass. Two volume controls, bass and treble control.
Separate switchable bass boost. Stand-by switch.
- Net weight (2.2 lb = 1 kg)
- 14.5 kg / 31 lb 15 oz (31.938 lb)
- Author
- Model page created by Edoardo Sigismondo. See "Data change" for further contributors.
