- Country
- Germany
- Manufacturer / Brand
- Stern-Radio Berlin, VEB, RFT, (Kombinat); - vorm. Phonetika Radio (Ostd.) - vorm. Loewe Opta AG
- Year
- 1989/1990
- Category
- Broadcast Receiver - or past WW2 Tuner
- Radiomuseum.org ID
- 132164
-
- alternative name: Phonetika Radio Berlin, VEB; Berlin, (Ostd.)
Click on the schematic thumbnail to request the schematic as a free document.
- Number of Transistors
- 22
- Semiconductors
- Main principle
- Superheterodyne (common); ZF/IF 455/10700 kHz
- Tuned circuits
- 3 AM circuit(s) 5 FM circuit(s)
- Wave bands
- Broadcast (BC) and FM or UHF.
- Details
- Cassette-Recorder or -Player
- Power type and voltage
- Line / Batteries (any type) / 220 / 6 x 1,5 Volt
- Loudspeaker
- 2 Loudspeakers
- Power out
- 3 W (unknown quality)
- Material
- Plastics (no bakelite or catalin)
- from Radiomuseum.org
- Model: SKR1100 - Stern-Radio Berlin, VEB, RFT,
- Shape
- Portable set > 8 inch (also usable without mains)
- Dimensions (WHD)
- 580 x 140 x 160 mm / 22.8 x 5.5 x 6.3 inch
- Notes
- Der Empfänger SKR1100 empfängt MW und UKW und enthält ein Stereo- Kassettenteil. Für AM und für FM sind je ein Piezofilter eingesetzt. Die Lautsprecher sind abnehmbar montiert, die NF- Endstufen liefern bei Batteriebetrieb eine Leistung von 2 x 1,5 Watt, bei Netzbetrieb 2 x 2,5 Watt. Ausstattungsmerkmale sind ein Equalizer, eine Abstimmungsanzeige, eine automatische Netz- Batterieumschaltung, automatische Aussteuerung und ein eingebautes Elektret- Mikrofon. Anschlußbuchsen für TA/ TB und für einen Stereo- Kopfhörer. Das Gerät ist teilweise SMD- bestückt.
- Net weight (2.2 lb = 1 kg)
- 4.4 kg / 9 lb 11.1 oz (9.692 lb)
- Price in first year of sale
- 1,650.00 DM
- Source of data
- - - Manufacturers Literature
- Mentioned in
- Die Geschichte der Fonoindustrie von 1945 bis 1990
- Literature/Schematics (1)
- Service-DVD Funkverlag B. Hein
- Author
- Model page created by Wolfgang MICHAEL. See "Data change" for further contributors.
