- Country
- Germany
- Manufacturer / Brand
- Stern-Radio Sonneberg, VEB, RFT; SONRA; -vorm.: EAK (Ostd.) - ex. AEG
- Year
- 1966
- Category
- Broadcast Receiver - or past WW2 Tuner
- Radiomuseum.org ID
- 185471
Bild von Messeprospekt 1966.
Click on the schematic thumbnail to request the schematic as a free document.
- Number of Tubes
- 4
- Main principle
- Superheterodyne (common); ZF/IF 455 kHz
- Tuned circuits
- 6 AM circuit(s)
- Wave bands
- Broadcast plus more than 2 Short Wave bands.
- Power type and voltage
- Alternating Current supply (AC) / 110; 127; 150; 180; 200; 220 Volt
- Loudspeaker
- Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil)
- Power out
- 3 W (unknown quality)
- Material
- Wooden case
- from Radiomuseum.org
- Model: Orietta 5500 - Stern-Radio Sonneberg, VEB,
- Shape
- Tablemodel with Push Buttons.
- Dimensions (WHD)
- 400 x 170 x 155 mm / 15.7 x 6.7 x 6.1 inch
- Notes
- Exportgerät, KW1=12,5-26,5 MHz; KW2=5,5-12,5 MHz; KW3= 2,3-5,5 MHz. Holzgehäuse mit Plasteinsatz.
- Source of data
- -- Original prospect or advert
- Author
- Model page created by Wolfgang Eckardt. See "Data change" for further contributors.
