Chromat 2369

Stern-Radio Staßfurt, VEB, RFT (Ostd.) - vorm. Staßfurter (Stassfurter)...

Data
Forum
Pictures
Collections

  • Year
  • 1979/1980
  • Category
  • Television Receiver (TV) or Monitor
  • Radiomuseum.org ID
  • 162534
    • alternative name: Fernsehgerätewerk Staßfurt

Click on the schematic thumbnail to request the schematic as a free document.

 Technical Specifications

  • Number of Tubes
  • 1
  • Number of Transistors
  • Semiconductors present.
  • Semiconductors
  • Main principle
  • Superheterodyne (common)
  • Wave bands
  • Wave Bands given in the notes.
  • Power type and voltage
  • Alternating Current supply (AC) / 220 Volt
  • Loudspeaker
  • Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil)
  • Material
  • Wooden case
  • from Radiomuseum.org
  • Model: Chromat 2369 - Stern-Radio Staßfurt, VEB, RFT
  • Shape
  • Tablemodel, low profile (big size).
  • Notes
  • VEB Fernsehgerätewerk Staßfurt Chromat 2369;
    ~61 cm SECAM Farb TV mit CCIR B/G Tuner und sechs Programmtasten, UHF nur Band IV, Tonregler, Modulchassis, im Gegensatz zu Chromat 2366/2367 hat der 2368/2369 ein Schaltnetzteil.
  • Author
  • Model page created by a member from A. See "Data change" for further contributors.
