• Country
• Germany

• Manufacturer / Brand
• Stern-Radio Staßfurt, VEB, RFT (Ostd.) - vorm. Staßfurter (Stassfurter)...

• Year
• 1956 ?

• Category
• Broadcast Receiver - or past WW2 Tuner

• Radiomuseum.org ID
• 78139

• • alternative name: Fernsehgerätewerk Staßfurt

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Tubes
• 8

• Valves / Tubes
• EC92 EC92 ECH81 EF89 EM80 EABC80 EL84 EZ80

• Main principle
• Superheterodyne (common); ZF/IF 468/6700 kHz

• Tuned circuits
• 6 AM circuit(s)     9 FM circuit(s)

• Wave bands
• Broadcast, Long Wave, Short Wave plus FM or UHF.

• Details
• Record Player (not changer)

• Power type and voltage
• Alternating Current supply (AC) / 110; 127; 220; 240 Volt

• Loudspeaker
• 2 Loudspeakers / Ø 20 cm = 7.9 inch

• Power out
• 3 W (unknown quality)

• Material
• Wooden case

• from Radiomuseum.org
• Model: Violetta 8E157 - Stern-Radio Staßfurt, VEB, RFT

• Shape
• Console with Push Buttons.

• Dimensions (WHD)
• 1120 x 890 x 440 mm / 44.1 x 35 x 17.3 inch

• Notes
• Musikschrank mit Radiochassis 8E157 Rienzi, stetige Klangfarbenregelung, gehörrichtige Lautstärkeregelung, mit 3-Touren-Plattenspieler. Gehäuse ähnlich Modell Caruso I.

• Net weight (2.2 lb = 1 kg)
• 57 kg / 125 lb 8.8 oz (125.551 lb)

• Price in first year of sale
• 1,310.00 DM

• External source of data
• Radio und Fernsehen 6/1956

• Source of data
• Radiokatalog Band 2, Ernst Erb

• Mentioned in
• Funkverlag Hein, Service-DVD

• Author
• Model page created by Michael Seiffert. See "Data change" for further contributors.
